Check what normal temperatures look like under load Laptops and handhelds run hotter than desktops, so read the numbers with that in mind.
On this page
The 680M arrived in early 2022 with the Ryzen 6000 “Rembrandt” chips, and it still turns up in new budget laptops and in handhelds like the GPD Win 4. It’s not the newest AMD integrated GPU anymore. The 780M and 890M are faster. But a well-cooled 680M machine at a good price can still be a sensible buy, as long as you know what you’re getting.
Radeon 680M specs at a glance
| Spec | Radeon 680M |
|---|---|
| Architecture | RDNA 2 (same family as the RX 6000 desktop cards) |
| Compute units | 12, with hardware ray tracing |
| Graphics clock | Up to 2,200 MHz on the Ryzen 7 6800H and 7735HS (some Ryzen 9 models clock higher) |
| Memory | Shares system RAM: DDR5-4800 or LPDDR5-6400, dual channel |
| Display outputs | HDMI 2.1, DisplayPort 2.0, up to 4 displays, FreeSync |
| Video encode | H.264 and H.265 (no AV1 encode) |
| Found in | Ryzen 9 6980HX/HS and 6900HX/HS, Ryzen 7 6800H/HS/U, Ryzen 7 7735HS and 7735U (Ryzen 5 models in these families use the smaller 660M) |
Specs are from AMD’s pages for the Ryzen 7 6800H and the Ryzen 7 7735HS. NotebookCheck’s 680M page lists up to 2.4 GHz on some models. The confusing bit: AMD’s “Ryzen 7000” laptop name covers several different chips. Only the 7035-series parts (like the 7735HS) use the 680M. The 7040-series parts (like the 7840HS) use the newer 780M.
What games can the Radeon 680M run?
Think esports and older AAA games at 1080p, and newer AAA games at low settings, often with upscaling or a drop to 720p or 900p. Competitive games like Fortnite, Valorant and CS2 are where it’s most comfortable.
We haven’t benchmarked a 680M machine ourselves, so for per-game frame rates go to NotebookCheck’s 680M benchmark list. It collects results from many reviewed laptops. Compare entries from devices with a similar processor and power limit to the one you’re looking at, because a 15W ultrabook and a 45W gaming laptop with the same 680M can be far apart.
Two hard limits. Ray tracing is supported on paper, but a 12-CU integrated GPU doesn’t have the headroom for it in most games. And 1440p or 4K gaming is out of reach outside very light titles. It’ll drive a 4K desktop monitor fine. It just won’t game on one.
How to get more out of a 680M laptop or handheld
Most of the speed difference between two 680M devices comes from things you can check or change.
- Run memory in dual channel. The 680M has no memory of its own, so a single RAM stick halves the bandwidth it can use. If your laptop has slots, two matching sticks are the single biggest upgrade. Soldered LPDDR5 is already dual channel.
- Give it power. On a laptop, plug in and pick the maker’s performance mode. On a handheld, the TDP setting in the maker’s software (AYANEO and GPD both have one) decides how fast the GPU can clock. More watts means more frames, more heat and shorter battery life. Find the lowest setting that keeps your game smooth.
- Check the VRAM setting. Many laptops let you set the dedicated share of RAM (often called UMA Frame Buffer Size) in the BIOS. AMD lists up to 2GB for the 6800H. A game that refuses to launch over “not enough video memory” sometimes starts after you raise it.
- Use upscaling. FSR in games that support it, set to Quality or Balanced, is usually a better trade than dropping to the lowest preset.
- Keep drivers current. AMD moved RDNA 2 graphics to its own driver branch in late 2025, but AMD told Tom’s Hardware that these chips, handhelds included, still get day-zero game support. If AMD’s installer refuses your laptop, use the laptop maker’s driver instead.
Laptops and handhelds will get hot under load. That’s normal up to a point. If clocks keep dropping in long sessions, a cooling pad or a lower TDP often gives steadier frame rates than running flat out. Thermal throttling is a sneaky thief: it never takes all your frames, just the ones you needed.
Radeon 680M vs 780M vs 890M
| Radeon 680M | Radeon 780M | Radeon 890M | |
|---|---|---|---|
| Architecture | RDNA 2 | RDNA 3 | RDNA 3.5 |
| Compute units | 12 | 12 | 16 |
| Graphics clock (example chip) | 2,200 MHz (Ryzen 7 6800H) | 2,700 MHz (Ryzen 7 7840U) | 2,900 MHz (Ryzen AI 9 HX 370) |
| Typical devices | Ryzen 7/9 6000 and Ryzen 7 7735 laptops, GPD Win 4, AYANEO 2 | Ryzen 7/9 7040 and 8040 laptops | Ryzen AI 9 HX 370 laptops |
Sources: AMD’s Ryzen 7 7840U page and Ryzen AI 300 quick reference guide.
The 780M has the same number of compute units on a newer design with higher clocks. It’s a step up, not a leap. The 890M adds four more compute units and is the one to get if integrated graphics gaming really matters to you. Either way, the laptop’s power limit and memory still decide a lot, the same as with the 680M.
Our take: if a 680M laptop is clearly cheaper than a 780M one with similar cooling and memory, the 680M is fine for esports and older games. If the gap is small, take the 780M. And if gaming is the main reason you’re buying, a laptop with even an entry-level dedicated GPU beats all three.
Radeon 680M vs Intel Iris Xe
For games, the 680M is the stronger chip. NotebookCheck’s integrated graphics comparison found it well ahead of Iris Xe, though the gap depends on how much power each laptop allows. For office work, video playback and web browsing, both are plenty. If you’re upgrading from an older Intel laptop, our Intel HD Graphics guide shows how far integrated graphics have come.
Coming from a laptop with Radeon Vega 10?
Vega 10 is the integrated GPU in older Ryzen laptop chips like the Ryzen 7 2700U (AMD, 2017) and Ryzen 7 3700U. Ryzen 5 parts from those years, like the 2500U and 3500U, have the smaller Vega 8. Vega 10 has 10 compute units on the older Vega design at up to about 1.3 to 1.4 GHz. The 680M has 12 newer RDNA 2 compute units at much higher clocks and uses faster DDR5 or LPDDR5, so it’s a big step up.
The memory tip applies even more to Vega laptops. Plenty of them shipped with a single RAM stick. Adding a matching second stick is cheap and makes a real difference.
Should you buy a Radeon 680M laptop now?
Buy one if the price is right and you mostly play lighter games, or you want a small handheld for older PC games. Check three things before you pay: dual-channel memory (16GB minimum, two sticks or soldered LPDDR5), decent cooling (read a review of that exact model), and the power limit the maker allows.
Skip it if you want to play new AAA games at decent settings. Spend the money on a 890M laptop or one with a dedicated GPU instead. Prices move a lot, so compare current listings rather than trusting any number printed in an article, this one included.
FAQ
Is the Radeon 680M good for gaming?
Yes, for esports and older games at 1080p, and for newer games at low settings with upscaling. It can’t handle ray tracing or high settings in demanding new games. Performance varies a lot with the laptop’s power limit and memory.
How much RAM does a Radeon 680M laptop need?
16GB in dual channel is the practical minimum, because the 680M borrows system memory for graphics. 32GB helps if you keep a browser and other apps open while gaming. Dual channel matters more than the total.
Is the 780M much faster than the 680M?
It’s faster, with the same 12 compute units on the newer RDNA 3 design and higher clocks. It’s a generational step rather than a big jump. The 16-CU 890M is the bigger upgrade.
Which Ryzen 7000 laptop chips have the 680M?
The Ryzen 7 7735HS and 7735U from the 7035 series. Ryzen 5 chips in that series use the smaller 660M. The 7040-series chips, such as the Ryzen 7 7840HS and 7840U, have the 780M instead.
Can I upgrade the graphics on a 680M laptop?
No. The 680M is part of the processor. You can improve it with faster, dual-channel memory and better cooling, but you can’t swap the GPU.
Sources
We haven’t run our own benchmarks on this hardware. Specs and status below come from the maker’s own pages and the named reviews, linked here.
- AMD: Ryzen 7 6800H specifications, checked 2026-10-24.
- AMD: Ryzen 7 7735HS specifications, checked 2026-10-24.
- AMD: Ryzen 7 7840U specifications (Radeon 780M), checked 2026-10-24.
- AMD: Ryzen AI 300 quick reference guide (Radeon 890M), checked 2026-10-24.
- NotebookCheck: Radeon 680M benchmarks and specs, checked 2026-10-24.
- NotebookCheck: Radeon 680M vs Iris Xe, checked 2026-10-24.
- Tom’s Hardware: AMD on RDNA 1 and 2 driver support, checked 2026-10-24.
- GPD: Win 4 specifications, checked 2026-10-24.
- AYANEO: AYANEO 2 specifications, checked 2026-10-24.
- AMD: 2017 Ryzen Mobile launch (Vega 8 and Vega 10), checked 2026-10-24.
