Intel Arc A770: Specs, Drivers and Whether It’s Still Worth It

by GigaScreens Team
A close-up shot of an Intel Arc A770 graphics card installed in a high-end gaming PC. The GPU is illuminated by blue LED lighting, with cooling fans in motion. The background shows a modern gaming setup with a dual-monitor display showing real-time GPU performance metrics. The image has sharp reflections, realistic lighting, and cinematic detail, emphasizing the futuristic power of Intel’s GPU. --ar 16:9 --v 6.0
Quick answer: If you already own an Arc A770, keep using it and make sure Resizable BAR is on. Buying now? Intel lists the A770 as end of life, and the Arc B580 is faster and draws less power, so pick the B580 unless a used A770 is much cheaper. The A770’s 16GB and AV1 encoder are still useful for streaming.
On this page

The A770 was Intel’s first serious desktop graphics card, launched in late 2022. Drivers improved a lot after a rough start. The bigger change since then is that Intel’s own next generation has arrived.

Arc A770 specs

Spec Arc A770 16GB
Architecture Xe-HPG (Alchemist), TSMC N6
Xe cores / ray tracing units 32 / 32
Graphics clock 2,100 MHz
Memory 16GB GDDR6, 256-bit, 560 GB/s
Total board power 225W
PCIe 4.0 x16
Video engines AV1, HEVC and H.264 encode and decode
Launch Q3 2022

All from Intel’s A770 16GB spec page. An 8GB version also exists, so check which one a listing actually is.

Turn on Resizable BAR first

This is the most common A770 problem, and it’s a setting. Intel says Resizable BAR (called Smart Access Memory on AMD boards) should be enabled for optimal performance on Arc A-series cards. The card still works without it, just slower (Intel support article).

Advertisement
  1. In your BIOS, turn off CSM (legacy boot) and boot in UEFI mode.
  2. Turn on Above 4G Decoding.
  3. Turn on Re-Size BAR Support.
  4. Back in Windows, Intel’s Arc software shows whether it’s active.

Not every older board offers the option. Intel’s article lists what’s needed. If yours doesn’t have it, that alone is a good reason not to put an A770 in that PC.

Is the A770 still supported?

As a product, it’s done. Intel has published an end-of-life notice for the Arc A770, so new stock is drying up. Driver support is a separate question from sales. Get drivers from Intel’s support site and check the release notes list your card before you install.

Arc A770 vs Arc B580

The B580 replaced the A-series. TechPowerUp’s Arc B580 review measured it 5% faster than an RTX 4060 at 1080p, and drawing 185W while gaming against 235W for the A770. TechPowerUp’s earlier RTX 4060 review put the A770 within 10% of the RTX 4060.

Advertisement

Put those together and the B580 is a bit faster and runs cooler. It has 12GB of VRAM against the A770’s 16GB, which rarely decides it at 1080p and 1440p. See our Arc B580 overview and B580 vs RTX 4060 comparison.

Our view: a used A770 is only a good buy when it’s clearly cheaper than a B580, and only in a PC with Resizable BAR.

What the A770 is still good at

Two things stand out. The 16GB of VRAM helps with high-resolution textures and local AI tools, and the AV1 encoder is handy for streaming and recording at good quality without huge files. If you already have one for those jobs, there’s no rush to replace it.

FAQ

Does the Arc A770 need Resizable BAR?

Intel says Resizable BAR should be enabled for optimal performance. Without it the card works, but performance drops.

Is the Intel Arc A770 discontinued?

Intel has published an end-of-life notice for the A770, so new stock is limited. Check Intel’s support site for current drivers.

Is the Arc B580 better than the A770?

Yes for most people. TechPowerUp measured the B580 slightly ahead of the RTX 4060, while the A770 was within 10% of it, and the B580 draws about 50W less while gaming.

Is the Arc A770 good for streaming?

Its hardware AV1, HEVC and H.264 encoders make it a solid streaming and recording card, as long as your streaming platform accepts the codec you choose.

Sources

We haven’t run our own benchmarks on this card. Figures below come from the maker’s spec pages and the named reviews, linked here.
